InteliCompact
NT
, SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
This is a bit array containing the status of physical binary inputs of the
IOM/PTM extension module. Bit0 represents BI1, bit1 represents BI2, etc.
NOTE:
In LiteEdit and on the controller screen this value is displayed in “normal
order”, i.e. BI1 in the leftmost position.
This is a bit array containing the status of physical binary inputs of the
extension plugin module. Bit0 represents ExM BI1, bit1 represents ExM BI2,
etc.
NOTE:
In the LiteEdit and on the controller screen this value is displayed in “normal
order”, i.e. ExM BI1 in the leftmost position.
This is a bit array containing the status of the LED indicators of the RA15
module. Bit0 represents the top left LED, bit14 represents the bottom right
LED.
NOTE:
In LiteEdit and on the controller screen this value is displayed in “normal
order”, i.e. bit0 in the leftmost position.
