Do not disassemble the internal power supply, as there are no field
serviceable parts inside.
>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>><<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<
To remove the internal AC power supply, complete the following steps:
1. Remove the keyboard cover (Section 4.7).
2. Remove the hinge cover from the top of the internal AC power supply by
sliding it toward the front of the unit (Figure 4-40).
3. Remove the two screws that attach the power supply to the top of the
system unit (Figure 4-41).
