Replacing the PCMCIA Compartment Door
To replace the PCMCIA compartment door, complete the following steps:
1. Position the door spring [1] over its retaining post [2] on the computer
base enclosure (Figure 4-55).
2. Position the long end of the spring [3] into its slot on top of the
computer base enclosure (Figure 4-55) so that it stays in place.
NOTE: The spring automatically goes into place when the door is
installed and closed.
