7.
Flex
the
top
cover
of
the
expansion
base
downward
[1]
to
slightly
widen
the
gap
between
the
drive
cages
(Figure
9-36).
8.
While
the
top
cover
is
flexed,
place
the
other
end
of
the
drive
cage
spacer
[2]
into
the
slot
on
the
other
drive
cage
[3],
and
release
the
tension
on
the
top
cover
(Figure
9-36).
279
