The emitter and receiver are similar in appearance. To tell them apart
easily, note that the receiver frame has one small hole [1] and the emitter
frame has two small holes [2] (Figure 9-44). The single hole in the
receiver frame corresponds with a single infra-red component on the
receiver board while the two holes in the emitter frame correspond with two
LEDs on the emitter board.
