Compaq LTE Elite - Page 292

7. Remove the keylock switch (Figure 9-48).
IMPORTANT: When replacing the keylock switch, it is possible to install
it upside down. Ensure that the switch actuator faces the
outside of the expansion base or the switch cannot function
(Figure 9-48).
