Replacing the Horizontal Guides and Springs
NOTE: One of the legs on each spring is straight and the other leg is bent.
Eject Switch Side
To replace the horizontal guide and spring for the eject switch side,
complete the following steps:
1. Position the spring so that the legs of the spring are on the top [1]
(Figure 9-55).
2. With the curved surface of the horizontal guide [2] facing right, place
the spring post of the horizontal guide [3] in the coil of the spring
[4]. Ensure that both legs of the spring are to the left of the
horizontal guide (Figure 9-55).
