Cosmo LS-R700 User Manual

128 10 Specifications
10
1
1
P
P
r
r
i
i
m
m
a
a
r
r
y
y
S
S
p
p
e
e
c
c
i
i
f
f
i
i
c
c
a
a
t
t
i
i
o
o
n
n
s
s
Differential
Pressure
Sensor
(Standard)
Resolution:
Display Range:
Accuracy Guaranteed Range:
Sensor Range:
Sensor Proof Pressure:
Reading Accuracy:
0.1 Pa
±999 Pa
±1000 Pa
±2000 Pa
5 MPa
±2.5% of rdg ±1Pa 50Pa or lower: ±2Pa *1
Test Pressure
Sensor
Reading Accuracy:
Temperature Characteristics:
±1% of F.S. ±1 digit (Linearity, Hysteresis and Repeatability)
±0.1% of F.S. / °C
Display Unit
*2
Test Pressure
kPa, MPa (PSI, kg/cm
2
, bar, mbar, mmHg, cmHg, inHg)
Leak *3 Pa, kPa, mL/s, mL/min, L/min, Pa·m
3
/s, E-3 Pa·m
3
/s, Pa/s, Pa/min, *Pa/s, *Pa/min
(mmH
2
O, inH
2
O, mmHg, in
3
/min, in
3
/d, ft
3
/h)
Leak Display
4 digits Sampling Rate: 10 times/s
Leak Limit Range (Standard)
±999.9 Pa
Number of Channels
32 channels (#0 to #31)
Timers
Up to 999.9 s (Resolution: 0.1 s)
Power Source 100 to 240 VAC ±10% at 50/60 Hz, 80 VA max
Fuse: T2.5A 250V
Dielectric strength voltage and resistance: 1400 VAC 10 sec, DC500 V 50 MΩ
Internal Solenoid Power Source: 24VDC
Test Pressure source Clean air regulated to the test pressure.
The source pressure must be sufficiently higher than the test pressure.
Pilot Pressure
Clean air regulated from 400 to 700 kPa
Tube Diameter
Rc(PT) 1/4: Test pressure, WORK and MASTER ports
6mm quick disconnect fitting: Pilot pressure
CPU
SH-2A 144MHz DRAM 8MB
LCD/TP
3.5 inch color LCD 320 x 240 dot (QVGA)
Ambient Temperature
Operation Temperature: 5 to 45°C Storage Temperature: -20 to 60°C
Humidity
80 %RH or less / no dew condensation
Mass
Approx. 10 kg (Standard model)
Control I/O Port
Input Signal: Start, Stop, etc. Output: Pass, UL Fail, LL Fail, etc.
RS232C Serial Communication
(D-sub 9 pins)
I/F fixed length
ID/F fixed length
Test parameters are transmitted as well as test results.
T/F fixed length
Only test results are transmitted
Others
Special formats
USB Port
Test Data
Judgment, Leak, Test pressure, Channel#, Timers, etc
Copying test parameters
csv file
Test Parameter Backup/Restore, System Backup/Restore, Firmware upgrade
Calibration / Maintenance Ports
M10 x 1.5 (O ring seal)
EP Regulator Repeatability: ±0.5% of F.S. or less
Temperature Characteristics: ±0.16% of F.S./°C
Standard Accessories Power cord For Japan: Rating: 125VAC/7A Length: 3m
For overseas: Rating: 250VAC/10A Length: 2m (CE conformed)
Quick mounting brackets, Control I/O connector, Operation manual CD,
Inspection record, Traceability documents
Environmental Conditions
(IEC 61010-1)
Over voltage category 2
Pollution degree 2
Altitude 2000m or lower
Protection class I
Place to use: indoor
*1 Reading Accuracy is only for the initial factory setting.
Reading accuracy after calibration will be ± 5% of :rdg ±1Pa.
For the option D4: DPS 10kPa, the reading accuracy is
± 5% of rdg ±0.01kPa.
*2 The units in ( ) are not available for SI unit restriction models.
*3
Use a power cord that complies with the
local standard and regulations.
NOTE
Refer to
“
1
1
1
1
REFERENCE
”
for the details.
