Cosmo LS-R700 User Manual

10 Specifications 129
10
2
2
M
M
o
o
d
d
e
e
l
l
C
C
l
l
a
a
s
s
s
s
i
i
f
f
i
i
c
c
a
a
t
t
i
i
o
o
n
n
s
s
LS-R700-A B C
A: Pneumatic Circuit
Intelligent 1 Pneumatic Circuit
A1
Large flow circuit with great sensor protection features
Intelligent 2 Pneumatic Circuit
A2
Equipped an equalization valve and additional self-check features to A1 circuit
Micro Volume Circuit AS01
For the parts whose volume is approx. 10 mL or smaller and the leak
specifications are quite small.
Small Volume A1 Circuit AS1
For the parts whose volume is approx. 100 mL or smaller and the leak
specifications are quite small.
Secondary Pressure Circuit
C
For external pressure (secondary pressure) test
B: Test Pressure and Regulator Range
Precision
Regulator
Model
Micro Low
L02
Test pressure range: 5 to 20 kPa (PS 20 kPa, Regulator: 200 kPa)
Low
L
Test pressure range:10 to 100 kPa (PS 100 kPa, Regulator: 200 kPa)
Medium
M
Test pressure range:50 to 800kPa (PS 1MPa, Regulator: 0.8 MPa)
High
H20
Test pressure range:2.0 MPa or lower (PS 2 MPa, without regulator)
Vacuum
V
Test pressure range: -5 to -100 kPa (PS -100 kPa)
EP
Regulator
Model *1
Low
LR
Test pressure range:10 to 95 kPa (PS 100 kPa, Regulator: 100 kPa)
Medium
MR
Test pressure range:50 to 800 kPa (PS 1MPa, Regulator: 0.9 MPa)
Vacuum
VR
Test pressure range: -5 to -75 kPa (PS -100 kPa, Regulator: -80 kPa)
*1 EP = Electropneumatic
C: Options
Calibrator J
Come with
CAL driving valve
for Leak Master
The valve open/close automatically during
K(Ve) calibration
and K(Ve) check.
Not available for H20 and H49 models
Leak Master is sold separately.
Bypass Circuit Ready without
Precision Regulator
B
Comes with a valve to control the separately sold Bypass Circuit Unit
The Bypass Circuit Unit is equipped with a precision regulator.
Nylon Filter Housing
RX02
Filter housing for the pilot pressure port is nylon.
RX03 Filter housings for the pilot pressure and test pressure ports are nylon.
DPS 10kPa *2
D4
Sensor range: ±10 kPa Display range: ±10 kPa Resolution: 1 Pa
Stop Valve Monitoring W Checks whether the stop valve on the WORK port is opened.
*2 DPS = Differential pressure sensor
