COTRUST CTH200 Series User Manual

CTH200 Series PLC User Manual
293
1—Write new default
0—No update
Bit6: Update current value
1—Write new current value
0—No update
Bit7: effective bit
1—Effective
0—Ineffective
INT_CFG
IN
Interrupt
configuration(reserved)
Byte
reserved
reserved
CV
IN
New current value
Dword
-2147483
648
~
+2147483
647
PV
IN
New default value
Dword
-2147483
648
~
+2147483
647
STATUS
OUT
Communication status sign
1—Communication timeout
Bool
0~1
Attached Table
Mode
Description
Input
MC253_HSC0
I0.0
I0.1
I0.2
MC253_HSC1
I0.4
I0.5
I0.6
0
Single phase counter with internal
direction control
Clock
1
Clock
Reset
3
Single phase counter with external
direction control
Clock
Direction
4
Clock
Direction
Reset
9
A/B phase orthogonal counter
Clock A
Clock B
10
Clock A
Clock B
Reset
Read modules HSC status instruction
① Function name: MC253_READ_HSC
② Function: Read HSC count status and current value
