Design and Function
Paypod™ Embedded Pay Station
Published by CPI
Rear view
13 Pay station lock – release
rotary knob and door
handle
14 Door handle with door feet
15 Door
16 Rotary knob – open door
3.1.2 Overview of Inside Operating Elements
Coin and Banknote Recycler Positions
The Paypod™ Embedded pay station may be
equipped with different banknote recyclers .
However, the general pay station design and the in-
side operating elements are the same:
Front view
1 Coin recycler
2 Banknote recycler
