Design and Function
Paypod™ Embedded Pay Station
Published by CPI
Coin Recycler with Open Payout Unit
Payout unit view
1 Color code for coin hopper position
2 Coin hopper
3 Coin return conveyor
3.6.1.2 Coin Recycler Key Locks
To keep your cash safe the coin recycler is closed with a
lock for the lid[1] and another for the payout unit in nor-
mal operation. In case of jams the authorized attendant
possessing the key may open the coin recycler lid by
means of the push-button[2] and the pull handle[3].
For any maintenance work the payout unit may be opened
by unlocking the bottom key lock[4].
Hand over the key to open the coin re-
cycler payout unit only to personnel al-
lowed to have direct access to the
cash.
Coin Recycler's Locks and Keys
