Front and rear view
1 Latch button – open upper rear flap
2 Upper rear flap
3 Top flap
4 Latch – open top flap
5 Banknote acceptance unit
6 Banknote insertion LEDs
7 Banknote insertion slot
8 Banknote payout LEDs
9 Banknote payout slot
10 Interlock system lever – remove loading unit (E24
only) and cash box
11 Lock – release interlock system lever
12 Cash box handle – remove cash box
13 Cash box
14 Lock – open cash box
15 Loader handle – remove loading unit
16 Lock – open loading unit
17 Loading unit (E24 only)
18 Recycling unit
19 Recycling unit
20 Latch – open spine
21 Lower rear flap
