CPI Paypod Embedded - Page 37

37
44000-UG-01-01-EN_CPI_Paypod Embedded Pay Station_User Guide_V1.1.pdf
Design and Function
Paypod™ Embedded Pay Station
Published by CPI
E23 Banknote Recycler
E24 Banknote Recycler
Please read here to understand the basic functionality and design of the E23/E24banknote recycler:
· Overview of E23/E24banknote recycler
· E23/E24banknote recycler key locks
· E23/E24banknote recycler status LED
· E23/E24banknote acceptance unit
· E23/E24banknote recycling units
· E23/E24banknote cash box
· E24banknote loading unit
38
40
40
42
43
44
45
