Paypod™ Embedded Pay Station
Operation
Published by CPI
Unlocking E24 Banknote Loading Unit
Opening E24 Banknote Loading Unit
5 Unlatch[C] the yellow lever[3] to lift the maximum
level detection plate[4][D].
The level flag[5] is no longer green but orange now.
6 Continue with refilling banknotes , or clearing a
banknote jam .
Lifting E24 Banknote Loading Unit's Maximum Detection Plate
