CHAMP-AV8 (VPX6-462) HARDWARE USER’S MANUAL CURTISS-WRIGHT
A-20 PROPRIETARY 826448 VERSION 5 MARCH 2015
CHAMP-AV8 P2 (PCIE EXPANSION) CONNECTOR PIN ASSIGNMENTS
The P2 connector is a 16 wafer VPX RT2 type connector shown in Figure A.10. The connector
provides two (2) four-lane (x4) PCIe ports on the CHAMP-AV8. The pinout tables are presented
in the order of the rows when looking from the backplane, (that is, i, h, g, f, e, d, c, b, a).
Figure A.10: CHAMP-AV8 VITA 46 P2 Connector
See Table A.9 on page A-21 for connector pin assignments and Table A.10 on page A-21 for
signal definitions.
Connector
Orientation:
i h g f e d c b a
VITA 46
P2 Wafer 1
to
P2 Wafer 16
