826448 VERSION 5 MARCH 2015 PROPRIETARY A-1
A
CONNECTOR PIN ASSIGNMENTS
IN THIS APPENDIX
This appendix provides the interface pinout information for each of the connectors on the
CHAMP-AV8. The following connectors are described:
• “Connector Overview” on page A-3
– “Backplane VPX Connectors” on page A-3
– “About VITA 46 and ANSI/VITA 65” on page A-4
– “CHAMP-AV8 I/O Mapping” on page A-8
– “Using the CHAMP-AV8 Pinout Configurator” on page A-10
• “Backplane VPX Connectors—Detailed Description” on page A-14
– “CHAMP-AV8 P0 Utility Connector Pin Assignments” on page A-14
– “Corresponding VPX Backplane J0 Utility Connector Pin Assignments” on page
A-16
– “CHAMP-AV8 P1 (SRIO Fabric) Connector Pin Assignments” on page A-17
– “Corresponding VPX Backplane J1 (SRIO Fabric) Connector Pin Assignments” on
page A-19
– “CHAMP-AV8 P2 (PCIe Expansion) Connector Pin Assignments” on page A-20
– “Corresponding VPX Backplane J2 (PCIe Expansion) Connector Pin Assignments”
on page A-22
– “CHAMP-AV8 P3 (XMC Site’s PMC User I/O) Connector Pin Assignments” on page
A-23
– “Corresponding VPX Backplane J3 (XMC Site’s PMC User I/O) Connector Pin
Assignments” on page A-25
– “CHAMP-AV8 P4 (Basecard I/O) Connector Pin Assignments” on page A-26
– “Corresponding VPX Backplane J4 (Basecard I/O) Connector Pin Assignments” on
page A-29
