CHAMP-AV8 (VPX6-462) HARDWARE USER’S MANUAL CURTISS-WRIGHT
A-30 PROPRIETARY 826448 VERSION 5 MARCH 2015
CHAMP-AV8 P5 (XMC USER I/O) CONNECTOR PIN ASSIGNMENTS
The P5 connector is a 16 wafer VPX RT2 type connector shown in Figure A.13. The connector
provides access to the XMC User I/O of the CHAMP-AV8. The pinout tables are presented in
the order of the rows when looking from the backplane, (that is, i, h, g, f, e, d, c, b, a).
Figure A.13: P5 XMC User I/O Connector
See Table A.18 on page A-31 for connector pin assignments and Table A.19 on page A-31 for
signal definitions.
P1
P0
P4
P2
P3
P6
Connector
Orientation:
i h g f e d c b a
VITA 46
P5 Wafer 1
to
P5 Wafer 16
