CURTISS-WRIGHT 1
826448 VERSION 5 MARCH 2015 PROPRIETARY A-63
RTM J7 Connector
Assignments
On the CHAMP-AV8, the XMC Site Differential User I/O signals are mapped to the RTM J7
connector as shown below in Table A.45.
Table A.45: RTM XMC Differential User I/O (J7) Pin Assignments
Signal Name J13 Pin J13 Pin Signal Name
XMC_DP0_P 1 2 XMC_DP10_P
XMC_DP0_N 3 4 XMC_DP10_N
XMC_DP1_P 5 6 XMC_DP11_P
XMC_DP1_N 7 8 XMC_DP11_N
XMC_DP2_P 9 10 XMC_DP12_P
XMC_DP2_N 11 12 XMC_DP12_N
XMC_DP3_P 13 14 XMC_DP13_P
XMC_DP3_N 15 16 XMC_DP13_N
XMC_DP4_P 17 18 XMC_DP14_P
XMC_DP4_N 19 20 XMC_DP14_N
XMC_DP5_P 21 22 XMC_DP15_P
XMC_DP5_N 23 24 XMC_DP15_N
XMC_DP6_P 25 26 XMC_DP16_P
XMC_DP6_N 27 28 XMC_DP16_N
XMC_DP7_P 29 30 XMC_DP17_P
XMC_DP7_N 31 32 XMC_DP17_N
XMC_DP8_P 33 34 XMC_DP18_P
XMC_DP8_N 35 36 XMC_DP18_N
XMC_DP9_P 37 38 XMC_DP19_P
XMC_DP9_N 39 40 XMC_DP19_N
N/C 4142N/C
N/C 4344N/C
N/C 4546N/C
N/C 4748N/C
N/C 4950N/C
N/C 5152N/C
N/C 5354N/C
N/C 5556N/C
GND 5758GND
GND 5960GND
GND 6162GND
GND 6364GND
