POWER REQUIREMENTS
Notes: 1. Power consumption (Watts) will vary depending on processor frequency, application
usage, and ambient temperature.
2. ±12VAux for XMC only (not used by CHAMP-AV8 basecard).
3. Vs3 (+5.0 VDC) is not used by the CHAMP-AV8.
4. VBAT is optional. VBAT sources current only when the board is shutdown or main power
is “off”. When the CPU is running, VBAT current is 0 Amps.
Power Supply
Requirements
• Base-board +12V P/S requirement (no XMC), typical current draw is less than 12A.
• Base-board AUX +3.3V P/S requirement, typical current draw is less than 0.3A.
Overall Thermal
Power Dissipation
• Thermal power dissipation (no XMC), typical dissipation is less than 135W.
Table 1.6: Power Requirements
Power Supply Requirements
(per ANSI/VITA 46.0-2007)
Mnemonic Description Nominal Value Tolerance
Vs1/Vs2 +12.0VDC 12.0V ± 5%
+3.3V_AUX +3.3VDC 3.3V ± 5%
+12V_AUX
(see Note 2)
+12VDC +12.0V ± 5%
-12V_AUX
(see Note 2)
-12 VDC -12.0V ± 5%
VBAT
(see Note 4)
Battery Backup +3.0 V +2.7V (min)
+3.5V (max)
See “Detailed Power Requirements” on page 2-3 for additional information.
