DIMENSIONS
Table 1.7 lists the physical dimensions of the CHAMP-AV8.
Notes: 1. Front panel hardware on air-cooled modules includes: injector/extractor handles, EMC
strip, alignment pin, and keying provisions in accordance with ANSI/VITA 1.1, American
National Standards for VME64 Extensions (and IEEE 1101.10).
2. Uses a full width thermal interface surface to maximize thermal performance which is a
small deviation from the IEEE 1101.2 standard, which calls for the thermal frame to be
notched for compatibility with card guides in a standard air-cooled chassis.
WEIGHT
Table 1.8 lists the weight of the CHAMP-AV8.
Table 1.7: CHAMP-AV8 Dimensions
Parameter Dimensions
Height 233.2 mm (9.181 in.)
Depth 159.8 mm (6.293 in.)
Table 1.8: CHAMP-AV8 Weight
Card Type Mass
Air-cooled CHAMP-AV8 Level 0 1.05kg
Air-cooled CHAMP-AV8 Level 100 1.15kg
Conduction-cooled CHAMP-AV8 Level 200 1.25kg
Note
Tolerance for the above numbers are +/- 0.05kg.
