CHAMP-AV8 (VPX6-462) HARDWARE USER’S MANUAL CURTISS-WRIGHT
A-52 PROPRIETARY 826448 VERSION 5 MARCH 2015
REAR TRANSITION MODULE (RTM)
The Rear Transition Module (RTM) facilitates connections to the various I/O ports of the
CHAMP-AV8.
An illustration of the various ports and the industry-standard connectors provided by the RTM
is shown below in Figure A.18.
Figure A.18: CHAMP-AV8 Rear Transition Module Views
Additional interfaces and controls are made available on the RTM PWB, as seen in Figure A.19,
“RTM Printed Wiring Board Component Side View,” on page A-53.
