J16 Row F Table A.35 lists the pin assignments for Row F of the connector referenced J16. This connector
is part of XMC site. The table maps the J16 Row F XMC User I/O signals to the corresponding
VITA 46/48 P5 connector pins of the CHAMP-AV8 board. The signals are routed as single ended
signals in accordance with the P5w3P6–X38s+X8d+X12d pattern defined in VITA 46.9.
Table A.35: XMC J16 User I/O Connector Description (Row F)
XMC J16
Row F Pin
Number
VITA 46/48
P5 Connector
Pin Number
Direction Description Electrical
Characteristics
J16-F1 P5-A3 I/O XMC_F01 connection to P5 connector Depends on XMC module
J16-F2 P5-C4 I/O XMC_F02 connection to P5 connector Depends on XMC module
J16-F3 P5-B4 I/O XMC_F03 connection to P5 connector Depends on XMC module
J16-F4 P5-B5 I/O XMC_F04 connection to P5 connector Depends on XMC module
J16-F5 P5-A5 I/O XMC_F05 connection to P5 connector Depends on XMC module
J16-F6 P5-C6 I/O XMC_F06 connection to P5 connector Depends on XMC module
J16-F7 P5-B6 I/O XMC_F07 connection to P5 connector Depends on XMC module
J16-F8 P5-B7 I/O XMC_F08 connection to P5 connector Depends on XMC module
J16-F9 P5-A7 I/O XMC_F09 connection to P5 connector Depends on XMC module
J16-F10 P5-C8 I/O XMC_F10 connection to P5 connector Depends on XMC module
J16-F11 P5-B8 I/O XMC_F11 connection to P5 connector Depends on XMC module
J16-F12 P5-B9 I/O XMC_F12 connection to P5 connector Depends on XMC module
J16-F13 P5-A9 I/O XMC_F13 connection to P5 connector Depends on XMC module
J16-F14 P5-C10 I/O XMC_F14 connection to P5 connector Depends on XMC module
J16-F15 P5-B10 I/O XMC_F15 connection to P5 connector Depends on XMC module
J16-F16 P5-B11 I/O XMC_F16 connection to P5 connector Depends on XMC module
J16-F17 P5-A11 I/O XMC_F17 connection to P5 connector Depends on XMC module
J16-F18 P5-C12 I/O XMC_F18 connection to P5 connector Depends on XMC module
J16-F19 P5-B12 I/O XMC_F19 connection to P5 connector Depends on XMC module
