CHAMP-AV8 (VPX6-462) HARDWARE USER’S MANUAL CURTISS-WRIGHT
A-26 PROPRIETARY 826448 VERSION 5 MARCH 2015
CHAMP-AV8 P4 (BASECARD I/O) CONNECTOR PIN ASSIGNMENTS
The P4 connector is a 16 wafer VPX RT2 type connector shown in Figure A.12. The connector
provides access to the basecard I/O of the CHAMP-AV8. The pinout tables are presented in the
order of the rows when looking from the backplane, (that is, g, f, e, d, c, b, a).
Figure A.12: P4 Basecard I/O Connector
See Table A.15 on page A-27 for the connector pin assignments and Table A.16 on page A-27
for signal definitions.
Connector
Orientation:
i h g f e d c b a
VITA 46
P4 Wafer 1
to
P4 Wafer 16
