CURTISS-WRIGHT 1
826448 VERSION 5 MARCH 2015 PROPRIETARY A-25
CORRESPONDING VPX BACKPLANE J3 (XMC SITE’S PMC USER I/O)
CONNECTOR PIN ASSIGNMENTS
CHAMP-AV8 to backplane J3 pin assignments are shown below in Table A.14.
Table A.14: VPX Backplane J3 Pin Assignments
Pin Row i
Signal
Row h
Signal
Row g
Signal
Row f
Signal
Row e
Signal
Row d
Signal
Row c
Signal
Row b
Signal
Row a
Signal
1 NC GND GND PMC_01 PMC_03 GND GND PMC_02 PMC_04
2 GND PMC_05 PMC_07 GND GND PMC_06 PMC_08 GND GND
3 NC GND GND PMC_09 PMC_11 GND GND PMC_10 PMC_12
4 GND PMC_13 PMC_15 GND GND PMC_14 PMC_16 GND GND
5 NC GND GND PMC_17 PMC_19 GND GND PMC_18 PMC_20
6 GND PMC_21 PMC_23 GND GND PMC_22 PMC_24 GND GND
7 NC GND GND PMC_25 PMC_27 GND GND PMC_26 PMC_28
8 GND PMC_29 PMC_31 GND GND PMC_30 PMC_32 GND GND
9 NC GND GND PMC_33 PMC_35 GND GND PMC_34 PMC_36
10 GND PMC_37 PMC_39 GND GND PMC_38 PMC_40 GND GND
11 NC GND GND PMC_41 PMC_43 GND GND PMC_42 PMC_44
12 GND PMC_45 PMC_47 GND GND PMC_46 PMC_48 GND GND
13 NC GND GND PMC_49 PMC_51 GND GND PMC_50 PMC_52
14 GND PMC_53 PMC_55 GND GND PMC_54 PMC_56 GND GND
15 NC GND GND PMC_57 PMC_59 GND GND PMC_58 PMC_60
16 GND PMC_61 PMC_63 GND GND PMC_62 PMC_64 GND GND
