REFERENCE DOCUMENTATION
Refer to the following standards for information about the specifications the CHAMP-AV8 is
designed for compliance with:
• VITA 46.0-2007 - Advance Module Format, R1.2
• VITA 46.3 - 4x Serial RapidIO Signal Mapping for VITA 46, Revision 0.5
• VITA 46.4 - PCI Express Mapping and Advanced Switch Signal Mapping for VITA 46,
Draft 0.5
• VITA 46.9 - VITA 46 PMC/XMC Pinout Mapping, Revision 0.9
• VITA 46.10 - Rear Transition Module for VITA 46, Revision 0.08
• VITA 42.0 - XMC Specification, Revision 0.29
• VITA 42.3-2006 - XMC PCI Express Protocol Layer Standard
• VITA 48.0 - Enhanced Rugged Design Implementation, Draft 0.17
• VITA 48.1 - Air Cooling applied to VITA 46, Draft 0.20
• VITA 48.2 - Conduction Cooling applied to VITA 46, Draft 0.14
• VITA 65 - OpenVPX System Specifications, ANSI/VITA 65-2010
• PCI Express Base Specification Revision 2.1., March 4, 2009, PCI-SIG
• Interface Between Data Terminal Equipment and Data Circuit-Terminating Equipment
Employing Serial Binary Data Interchange, ANSI/TIA/EIA-232-F-1997, September 30,
1997
• RapidIO Interconnect Specification, Part IV: Physical Layer 1x/4x, LP Serial Specifica-
tion, Revision 1.2, June 2002
• Interface Between Data Terminal Equipment and Data Circuit-Terminating Equipment
Employing Serial Binary Data Interchange, ANSI/TIA/EIA-232-F-1997, September 30,
1997
• Electrical Characteristics of Balanced Voltage Digital Interface Circuits
(ANSI/TIA/EIA-422-B-1994) (R2000) (R2005), May 1994
• XMC PCI Express Protocol Layer Standard, ANSI/VITA 42.3-2006, 2006
• IEEE Standard for Information Technology, Part 3: Carrier Sense Multiple Access with
Collision Detection (CSMA/CD) Access Method and Physical Layer Specifications, IEEE
802.3-2008, 2008
