CHAMP-AV8 (VPX6-462) HARDWARE USER’S MANUAL CURTISS-WRIGHT
A-50 PROPRIETARY 826448 VERSION 5 MARCH 2015
J16 Row E Table A.33 lists the pin assignments for Row E of the connector referenced J16. This connector
is part of XMC site. The table maps the J16 Row E XMC User I/O signals to the corresponding
VITA 46/48 P5 or P6 connector pins of the CHAMP-AV8 board. The signals are routed as high
speed differential signals in accordance with the P5w3P6–X38s+X8d+X12d pattern defined in
VITA 46.9.
Table A.34: XMC J16 User I/O Connector Description (Row E)
XMC J16
Row E Pin
Number
VITA 46/48
P5/P6 Connector
Pin Number
Direction Description Electrical
Characteristics
J16-E1 P5-A13 I/O XMC_DP1_N connection to P5 connector Depends on XMC module
J16-E2 GND GND GND
J16-E3 P5-B14 I/O XMC_DP3_N connection to P5 connector Depends on XMC module
J16-E4 GND GND GND
J16-E5 P6-A1 I/O XMC_DP5_N connection to P6 connector Depends on XMC module
J16-E6 GND GND GND
J16-E7 P6-B2 I/O XMC_DP7_N connection to P6 connector Depends on XMC module
J16-E8 GND GND GND
J16-E9 P6-A3 I/O XMC_DP9_N connection to P6 connector Depends on XMC module
J16-E10 GND GND GND
J16-E11 P5-A15 I/O XMC_DP11_N connection to P5 connector Depends on XMC module
J16-E12 GND GND GND
J16-E13 P5-B16 I/O XMC_DP13_N connection to P5 connector Depends on XMC module
J16-E14 GND GND GND
J16-E15 P6-B4 I/O XMC_DP15_N connection to P6 connector Depends on XMC module
J16-E16 GND GND GND
J16-E17 P6-A5 I/O XMC_DP17_N connection to P6 connector Depends on XMC module
J16-E18 GND GND GND
J16-E19 P6-B6 I/O XMC_DP19_N connection to P6 connector Depends on XMC module
