32 P3-B8 P3-C8/J14-30 I/O J14-32 connection to P3 connector
33 P3-E9 P3-D9/J14-35 I/O J14-33 connection to P3 connector
34 P3-B9 P3-A9/J14-36 I/O J14-34 connection to P3 connector
35 P3-D9 P3-E9/J14-33 I/O J14-35 connection to P3 connector
36 P3-A9 P3-B9/J14-34 I/O J14-36 connection to P3 connector
37 P3-F10 P3-E10/J14-39 I/O J14-37 connection to P3 connector
38 P3-C10 P3-B10/J14-40 I/O J14-38 connection to P3 connector
39 P3-E10 P3-F10/J14-37 I/O J14-39 connection to P3 connector
40 P3-B10 P3-C10/J14-38 I/O J14-40 connection to P3 connector
41 P3-E11 P3-D11/J14-43 I/O J14-41 connection to P3 connector
42 P3-B11 P3-A11/J14-44 I/O J14-42 connection to P3 connector
43 P3-D11 P3-E11/J14-41 I/O J14-43 connection to P3 connector
44 P3-A11 P3-B11/J14-42 I/O J14-44 connection to P3 connector
45 P3-F12 P3-E12/J14-47 I/O J14-45 connection to P3 connector
46 P3-C12 P3-B12/J14-48 I/O J14-46 connection to P3 connector
47 P3-E12 P3-F12/J14-45 I/O J14-47 connection to P3 connector
48 P3-B12 P3-C12/J14-46 I/O J14-48 connection to P3 connector
49 P3-E13 P3-D13/J14-51 I/O J14-49 connection to P3 connector
50 P3-B13 P3-A13/J14-52 I/O J14-50 connection to P3 connector
51 P3-D13 P3-E13/J14-49 I/O J14-51 connection to P3 connector
52 P3-A13 P3-B13/J14-50 I/O J14-52 connection to P3 connector
53 P3-F14 P3-E14/J14-55 I/O J14-53 connection to P3 connector
54 P3-C14 P3-B14/J14-56 I/O J14-54 connection to P3 connector
55 P3-E14 P3-F14/J14-53 I/O J14-55 connection to P3 connector
56 P3-B14 P3-C14/J14-54 I/O J14-56 connection to P3 connector
57 P3-E15 P3-D15/J14-59 I/O J14-57 connection to P3 connector
58 P3-B15 P3-A15/J14-60 I/O J14-58 connection to P3 connector
59 P3-D15 P3-E15/J14-57 I/O J14-59 connection to P3 connector
60 P3-A15 P3-B15/J14-58 I/O J14-60 connection to P3 connector
61 P3-F16 P3-E16/J14-63 I/O J14-61 connection to P3 connector
62 P3-C16 P3-B16/J14-64 I/O J14-62 connection to P3 connector
63 P3-E16 P3-F16/J14-61 I/O J14-63 connection to P3 connector
64 P3-B16 P3-C16/J14-62 I/O J14-64 connection to P3 connector
Table A.25: J14 Connector Description (Pn4/Jn4 User Defined I/O) (Continued)
