CHAMP-AV8 (VPX6-462) HARDWARE USER’S MANUAL CURTISS-WRIGHT
B-4 PROPRIETARY 826448 VERSION 5 MARCH 2015
Table Note 1: The memory is write-protected if the stated condition is met.
Table Note 2: A software procedure must be performed to initiate the configuration before the
jumper setting can take affect.
Serial Flash
(4 devices)
4 Mbit Non-volatile Contains configuration
settings for the 82574
Ethernet controllers
Yes The memory is pro-
tected if jumper (or
wire-wrap) JB4 is
NOT installed.
RTM SW12 must be
Off
Backplane NVRMO
signal must be logic
High.
None
EEPROM Dip
Switch
24 bits Non-volatile Board configuration Yes The memory is pro-
tected if jumper (or
wire-wrap) JB4 is
NOT installed.
RTM SW12 must be
Off
Backplane NVRMO
signal must be logic
high
None
DDR3
SPD
EEPROM
(4 devices)
4kbit Non-volatile Contains DDR3 configu-
ration settings
Yes The memory is pro-
tected if jumper (or
wire-wrap) JB4 is
NOT installed.
RTM SW12 must be
Off
Backplane NVRMO
signal must be logic
High
None
Table B.1: Memory Devices Available On The CHAMP-AV8 (Continued)
Memory Type Size Volatility Function Accessible
from CPU
Write-protection
(Note 1)
Process to
Clear
