VPX P0 Utility
Connector
The backplane P0 provides power supplies, testing, clock, and I2C utilities, etc, for the VPX
system. With reference to Figure A.3 on page A-5, the CHAMP-AV8 P0 connector uses the
following combination of wafers:
VPX P1 - P6
Connectors
The P1 to P6 connectors provide Open-VPX SRIO Data Plane links and GE Control Plane links,
and employ the following wafers:
Table A.1: Wafer Usage - CHAMP-AV8 P0 Utility Connector
Wafer Number Wafer Type
1 Power
2 Power
3 Power
4 Single-Ended
5 Single-Ended
6 Single-Ended
7 Differential (odd)
8 Differential (even)
Table A.2: Wafer Usage - CHAMP-AV8 P1-P6 Connectors
Wafer Number Wafer Type
1 Differential (odd)
2 Differential (even)
3 Differential (odd)
4 Differential (even)
5 Differential (odd)
6 Differential (even)
7 Differential (odd)
8 Differential (even)
9 Differential (odd)
10 Differential (even)
11 Differential (odd)
12 Differential (even)
13 Differential (odd)
14 Differential (even)
15 Differential (odd)
16 Differential (even)
