Linea Lite GigE Series Camera Operational Reference • 77
Direction Source sensorScanDirectionSource Direction determined by value of: Beginner
Internal
Internal
Internal Scan Direction feature.
RotaryEncoder Encoder Rotary encoder. Channel A and B from encoder
go to GPIO 1 and GPIO 2, respectively.
Direction is determined from phase.
Available when Trigger Source
is Encoder and
Rotary Encoder Output Mode is Motion (see I/O
Control category).
Line 1 GPIO1
Pin 1 (Low: forward, high: reverse). Available
when Trigger Source
e is not Rotary Encoder.
Line 2 GPIO2
Pin 3 (Low: forward, high: reverse). Available
when Trigger Source
is not Rotary Encoder.
Line 3 GPIO3
Pin 6 (Low: forward, high: reverse). Available
when Trigger Source
is not Rotary Encoder.
Internal Scan Direction sensorScanDirection Specifies the scan direction when
Direction
Source is set to Internal,
Beginner
DFNC
Forward Forward Forward scan direction.
Reverse Reverse Revers scan direction
Gain Selector
GainSelector
Selects which gain is controlled when adjusting
gain features.
Beginner
Digital DigitalAll
Apply a digital gain adjustment to the entire
image. Gain applied after row gains.
Final digital gain = (Row gain * Digital gain)
Sensor Analog SensorAnalog Sensor analog gain. Possible values are 0.6 -1.
Digital Row 1 DigitalRow1 Gain applied to first sensor row.
Available only when Sensor TDI Mode
is High
Dynamic Range or Multi-Row.
Digital Row 2 DigitalRow2 Gain applied to second sensor row.
Available only when Sensor TDI Mode
is High
Dynamic Range or Multi-Row.
Digital Red DigitalRed Gain applied to red channel. Available for color
models only.
Digital Blue DigitalBlue Gain applied to blue channel. Available for color
models only.
Digital Green DigitalGreen Gain applied to green channel. Available for
color models only.
Gain Gain
Sets the selected gain as an amplification factor
applied to the image.
Beginner
Black Level Selector BlackLevelSelector
Selects which tap is controlled by the Black
Level feature.
Beginner
Digital DigitalAll Digital black level offset.
Black Level (in DN) BlackLevel Black level (offset) in DN.
Expert
Parallax Correction Pixel
Stretch
ParallaxCorrectionPixelStretch Sets the parallax correction value of the
selected line.
Beginner
DFNC
Parallax Correction Line
Selector
ParallaxCorrectionLineSelector
Selects the line to adjust the parallax
correction.
Red_Blue Red_Blue Red and blue line.
Green Green Green line.
