Danfoss Turbocor TT Series User Manual

Figure 4-180 Snubber Capacitor Removal - TTS300/TGS230
4. RemovethenylonnutsatthebaseoftheDCCapacitorBusBarAssembly,underthemaincompressor
housing.RefertoFigure4-181CapacitorNutRemoval-TTS300/TGS230.
Figure 4-181 Capacitor Nut Removal - TTS300/TGS230

5. CarefullylifttheDCBusBarsandcapacitorsoutasanassembly.Donotremovethebleedresistorsor
capacitorsfromthebusbars.RefertoFigure4-182CapacitorAssemblyRemoval-TTS300/TGS230on
page170.
• • • DANGER! • • •
BleedResistorsandbusbarsmayhavesharpedges.Usecautionandwearappropriateprotectivegearwhenremovingthecapacitor
assembly.





M-SV-001-EN Rev. H-1/23/2023 Page 169 of 294
