Datalogic QuickScan Lite QW2100 User Manual

Symbologies
108 QuickScan
TM
Lite QW2100
ENTER/EXIT PROGRAMMING MODE
UPC/EAN Global Settings — cont.
UPC/EAN Stitch Unlike Label Halves
Enables/disables the ability to stitch two UPC-A/EAN 13 label halves together that may have
differing characters in them.
NOTE
The label half structures must have the structure GddddddC and
CddddddG. The characters dCd must match between the two seg-
ments.
$CUNSU00
UPC/EAN Stitch Unlike Label Halves = Disable
$CUNSU01

UPC/EAN Stitch Unlike Label Halves = Enable
DEFAULT

Datalogic QuickScan Lite QW2100 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	EAN 5, EAN-13, EAN-8, GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	340 mA
Power source type	DC
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	65 mm
Width	170 mm
Height	70 mm
Weight	119 g
