Datalogic QuickScan Lite QW2100 User Manual

GS1 DataBar
TM
Omnidirectional
Product Reference Guide 119
ENTER/EXIT PROGRAMMING MODE
GS1 DataBarTM Omnidirectional — cont.
GS1 DataBar Omnidirectional Minimum Reads
This feature specifies the minimum number of consecutive times a GS1 DataBar Omnidirec-
tional label must be decoded before it is accepted as good read.
$C4BMR01
GS1 DataBar Omnidirectional Minimum Reads = 1
$C4BMR02

GS1 DataBar Omnidirectional Minimum Reads = 2
$C4BMR03

GS1 DataBar Omnidirectional Minimum Reads = 3
$C4BMR04

GS1 DataBar Omnidirectional Minimum Reads = 4
DEFAULT

Datalogic QuickScan Lite QW2100 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	EAN 5, EAN-13, EAN-8, GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	340 mA
Power source type	DC
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	65 mm
Width	170 mm
Height	70 mm
Weight	119 g
