References
262 QuickScan
TM
Lite QW2100
Label ID: Pre-loaded Sets
The following table lists the pre-loaded label ID sets for the USA and Europe.
Table 17. Label ID Pre-loaded Sets
Symbology USA Label ID set EU Label ID set
ASCII
character
Hex
value
ASCII
character
Hexidecimal
value
ABC Codabar
S 530000 S 530000
CODABAR
% 250000 R 520000
Codablock F
l 6C0000 m 6D0000
Code 39 CIP
Y 590000 Y 590000
Code 93
& 260000 U 550000
CODE11
CE 434500 b 620000
CODE128
# 230000 T 540000
CODE32
A 410000 X 580000
CODE39
* 2A0000 V 560000
CODE4
4 340000 4 340000
CODE5
j 6A0000 j 6A0000
CODE93
& 260000 U 550000
DATALOGIC 2OF5
s 730000 s 730000
EAN13
F 460000 B 420000
EAN13 P2
F 460000 L 4C0000
EAN13 P5
F 460000 M 4D0000
EAN13 P8
F 460000 # 230000
EAN8
FF 464600 A 410000
EAN8 P2
FF 464600 J 4A0000
EAN8 P5
FF 464600 K 4B0000
EAN8 P8
FF 464600 * 2A0000
FOLLETT 2OF5
O 4F0000 O 4F0000
GS1 DATABAR EXPANDED
RX 525800 t 740000
GS1 DATABAR LIMITED
RL 524C00 v 760000
GS1 DATABAR OMNIDIRECTIONAL
R4 523400 u 750000
GS1-128
000000 k 6B0000
I2OF5
i 690000 N 4E0000

Datalogic QuickScan Lite QW2100 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	EAN 5, EAN-13, EAN-8, GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	340 mA
Power source type	DC
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	65 mm
Width	170 mm
Height	70 mm
Weight	119 g
