Product Reference Guide 67
Chapter 9
Data Editing
Data Editing Overview
When a bar code is scanned, additional information can be sent to the host computer along
with the bar code data. This combination of bar code data and supplementary user-defined data
is called a “message string.” The features in this chapter can be used to build specific user-
defined data into a message string.
There are several types of selectable data characters that can be sent before and after scanned
data. You can specify if they should be sent with all symbologies, or only with specific symbolo-
gies. Figure 6 shows the available elements you can add to a message string:
Figure 6. Breakdown of a Message String
NOTE
Additional advanced editing is available. See the Advanced Formatting fea-
tures in the Datalogic Aladdin Configuration Application or contact
Tech ni -
cal Support on page 3
for more information.
Prefix SuffixAIM IDLabel ID Label IDBar Code Data
00 - 20 Characters (ASCII)
Label ID Transmission:
Enable this option to
transmit the Label ID you
configure for the scanned
symbology.
AIM ID: This function is used to identify and display the
common label identifier for its symbology. When enabled,
this ID code will be transmitted before the scanned bar
code data.
OR...
To Next Page
