Datalogic QuickScan Lite QW2100 User Manual

Scanning Features
Product Reference Guide 31
ENTER/EXIT PROGRAMMING MODE
Stand Mode Triggered Timeout
This feature specifies the time to remain in Trigger Single mode after the trigger is pulled while in
Stand Mode.
NOTE
This timeout is only used when the Scan Mode is configured as
Stand Mode.
$CSNOT01
Stand Mode Triggered Timeout = 0.5 Seconds
$CSNOT03

Stand Mode Triggered Timeout = 1.5 Seconds
$CSNOT04

Stand Mode Triggered Timeout = 2 Seconds
$CSNOT06

Stand Mode Triggered Timeout = 3 Seconds
$CSNOT08

Stand Mode Triggered Timeout = 4 Seconds
DEFAULT

Datalogic QuickScan Lite QW2100 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	EAN 5, EAN-13, EAN-8, GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	340 mA
Power source type	DC
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	65 mm
Width	170 mm
Height	70 mm
Weight	119 g
