Datalogic QuickScan Lite QW2100 User Manual

Caps Lock State
Product Reference Guide 57
ENTER/EXIT PROGRAMMING MODE
Caps Lock State
This option specifies the format in which the reader sends character data. This applies to Key-
board Wedge interfaces.
This does not apply when an alternate key encoding keyboard is selected.
Numlock
This option specifies the setting of the Numbers Lock (Numlock) key while in Keyboard Wedge
interface. This only applies to alternate key encoding interfaces.
It does not apply to USB Keyboard.
$CKBCL00
Caps Lock State = Caps Lock OFF
$CKBCL01

Caps Lock State = Caps Lock ON
$CKBCL02

Caps Lock State = AUTO Caps Lock Enable
DEFAULT
$CKBNL00
Numlock = Numlock key unchanged
$CKBNL01

Numlock = Numlock key toggled
DEFAULT

Datalogic QuickScan Lite QW2100 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	EAN 5, EAN-13, EAN-8, GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	340 mA
Power source type	DC
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	65 mm
Width	170 mm
Height	70 mm
Weight	119 g
