Datalogic QuickScan Lite QW2100 User Manual

Symbologies
176 QuickScan
TM
Lite QW2100
ENTER/EXIT PROGRAMMING MODE
Codabar — cont.
Codabar Quiet Zones
This feature specifies the number of quiet zones for Codabar labels. Quiet zones are blank areas
at the ends of a bar code and are typically 10 times the width of the narrowest bar or space in the
label.
$CCBLO01
Codabar Quiet Zones = Quiet Zone on one side
$CCBLO02

Codabar Quiet Zones = Quiet Zones on two sides
$CCBLO03

Codabar Quiet Zones = Auto
$CCBLO04

Codabar Quiet Zones = Virtual Quiet Zones on two sides
$CCBLO05

Codabar Quiet Zones = Small Quiet Zones on two sides
DEFAULT

Datalogic QuickScan Lite QW2100 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	EAN 5, EAN-13, EAN-8, GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	340 mA
Power source type	DC
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	65 mm
Width	170 mm
Height	70 mm
Weight	119 g
