Datalogic QuickScan Lite QW2100 User Manual

Code 32 (Italian Pharmaceutical)
Product Reference Guide 141
ENTER/EXIT PROGRAMMING MODE
Code 32 (Italian Pharmaceutical) — cont.
Code 32 Check Character Transmission
Enable this option to transmit the check character along with Code 32 bar code data.
Code 32 Start/Stop Character Transmission
This option enables/disable transmission of Code 32 start and stop characters.
$CP3CT00
Code 32 Check Character Transmission = Don’t Send
$CP3CT01

Code 32 Check Character Transmission = Send
DEFAULT
$CP3SS00
Code 32 Start/Stop Character Transmission = Don’t Transmit
$CP3SS01

Code 32 Start/Stop Character Transmission = Transmit
DEFAULT

Datalogic QuickScan Lite QW2100 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	EAN 5, EAN-13, EAN-8, GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	340 mA
Power source type	DC
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	65 mm
Width	170 mm
Height	70 mm
Weight	119 g
