Datalogic QuickScan Lite QW2100 User Manual

Symbologies
186 QuickScan
TM
Lite QW2100
ENTER/EXIT PROGRAMMING MODE
ABC Codabar — cont.
ABC Codabar Dynamic Concatenation Timeout
Specifies the timeout in 10-millisecond ticks used by the ABC Codabar Dynamic Concatena-
tion Mode.
$CCBDT05
ABC Codabar Dynamic Concatenation Timeout = 50 msec
$CCBDT0A

ABC Codabar Dynamic Concatenation Timeout = 100 msec
$CCBDT14

ABC Codabar Dynamic Concatenation Timeout = 200 msec
$CCBDT32

ABC Codabar Dynamic Concatenation Timeout = 500 msec
$CCBDT4B
ABC Codabar Dynamic Concatenation Timeout = 750 msec
$CCBDT64

ABC Codabar Dynamic Concatenation Timeout = 1 Second
DEFAULT

Datalogic QuickScan Lite QW2100 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	EAN 5, EAN-13, EAN-8, GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	340 mA
Power source type	DC
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	65 mm
Width	170 mm
Height	70 mm
Weight	119 g
