Datalogic QuickScan Lite QW2100 User Manual

Symbologies
230 QuickScan
TM
Lite QW2100
ENTER/EXIT PROGRAMMING MODE
Codablock F — cont.
Codablock F Set Length 2
This feature specifies one of the bar code lengths for Codablock F Length Control. Length 2
is the maximum label length if in Variable Length Mode, or the second fixed length if in
Fixed Length Mode. Length includes the bar code’s check, data, and full-ASCII shift charac-
ters. The length does not include start/stop characters.
The length can be set from 3 to 255 characters. A setting of 00 specifies to ignore this length
(only one fixed length). See Set Length 2 on page 269 for more detailed programming
instructions.
$CCFL2
Select Codablock F Length 2 Setting
Make a mistake? Scan the CANCEL bar code to abort and not
save the entry string. You can then start again at the beginning.
~
CANCEL
DEFAULT
100 = Length 2 is 100 Characters

Datalogic QuickScan Lite QW2100 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	EAN 5, EAN-13, EAN-8, GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	340 mA
Power source type	DC
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	65 mm
Width	170 mm
Height	70 mm
Weight	119 g
