Datalogic QuickScan Lite QW2100 User Manual

Keyboard Send Control Characters
Product Reference Guide 59
ENTER/EXIT PROGRAMMING MODE
Keyboard Send Control Characters
This feature is used by the Keyboard Wedge and USB Keyboard interfaces. It specifies how the
reader transmits ASCII control characters to the host. Reference Appendix F, Scancode
Ta bles for more information about control characters.
Options are as follows:
Send Ctrl+Key — ASCII characters from 00H to 0x1FH inclusive are transmitted in the for-
mat Ctrl+Key. Special keys are available in the range from 81H to A1.
Send Ctrl+Shift+Key — The behavior is the same as above, but control keys are sent in the
format Ctrl+Shift+Keys.
Send Special Function Key — Send characters between 00H and 1FH according to the spe-
cial function key mapping table (see Microsoft Windows Codepage 1252 on page 310).
This is used to send keys that are not in the normal ASCII set. A unique set is provided for each
available scancode set.
$CKBSC00
Keyboard Send Control Characters = 00
$CKBSC01

Keyboard Send Control Characters = 01
$CKBSC02

Keyboard Send Control Characters = 02
DEFAULT

Datalogic QuickScan Lite QW2100 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	EAN 5, EAN-13, EAN-8, GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	340 mA
Power source type	DC
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	65 mm
Width	170 mm
Height	70 mm
Weight	119 g
