Datalogic QuickScan Lite QW2100 User Manual

Global AIM ID
Product Reference Guide 69
ENTER/EXIT PROGRAMMING MODE
Global AIM ID
AIM label identifiers (as opposed to custom characters you select yourself as with label identifi-
ers) can be included with scanned bar code data. See Global AIM ID on page 261 for more
detailed programming instructions.
GS1-128 AIM ID
If Global AIM ID is disabled, the AIM ID for GS1-128 can be enabled/disabled independently.
The AIM ID for GS1-128 is a ]C1, ]C2 or ]C3.
AIM IDs for other symbologies can be enabled/disabled independently as well. Contact Cus-
tomer Support for assistance.
NOTE
This feature enables/disables addition of AIM IDs for all symbology
types.
$CAIEN00
Global AIM ID = Disable
$CAIEN01

Global AIM ID = Enable
DEFAULT
$CU8AI00
GS1-128 AIM ID = Disable
$CU8AI01

GS1-128 AIM ID = Enable
DEFAULT

Datalogic QuickScan Lite QW2100 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	EAN 5, EAN-13, EAN-8, GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	340 mA
Power source type	DC
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	65 mm
Width	170 mm
Height	70 mm
Weight	119 g
