Datalogic QuickScan Lite QW2100 User Manual

Indicate Transmission Failure
Product Reference Guide 51
ENTER/EXIT PROGRAMMING MODE
Indicate Transmission Failure
This option enables/disables the reader’s ability to sound an error beep to indicate a transmission
failure while in ACK/NAK mode.
Disable Character
Specifies the value of the RS-232 host command used to disable the reader.
ASCII characters or any hex value from 0 to 0xFF can be selected. See Disable Character on
page 255 for more detailed programming instructions.
$CR2TF00
Indicate Transmission Failure = Disable Indication
$CR2TF01

Indicate Transmission Failure = Enable Indication
DEFAULT
NOTE
Setting to previously defined characters such as XON, XOFF, or host
commands conflicts with normal operation of these characters. 8-bit
data is not recognized when the option
Data Bits has been set as 7
Data Bits.
$CR2DC
Select Disable Character Setting
DEFAULT
0x44 = Disable Character is ‘D’

Datalogic QuickScan Lite QW2100 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	EAN 5, EAN-13, EAN-8, GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	340 mA
Power source type	DC
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	65 mm
Width	170 mm
Height	70 mm
Weight	119 g
