Datalogic QuickScan Lite QW2100 User Manual

Product Reference Guide 311
Index
B
bar codes
RS-232
baud rate 63
RS-232 parameters
parity 231, 232, 234, 236
barcodes
cancel 297
numeric barcodes 297
RS-232 parameters
parity 56
Beeper
Pitch, Good Read 24, 25
Volume, Good Read 28
Beeper, Good Read 22
C
Cable Pinouts 273
Clear to Send 41
Conversion, case 81
Conversion, character 82, 266
CTS 41
D
Decode Capability 272
Defaults 275
Depth of Field 271
E
Electrical Safety 272
EMI/RFI 272
Error Codes 291
Errors 291
G
Good Read, Beeper 22
Pitch 24, 25
Volume 28
Good Read, Beeper – 22
Good Read, Beeper Pitch – 24, 25
Good Read, Beeper Volume – 28
Green Spot 289
H
Handheld Scanner 66
I
Indications 289
Interface Cable 6
Interface Type 9
Interfaces Supported 272
K
keyboard support 54
KEYBOARD WEDGE (KBW) interface
selection 13
Keyboard Wedge Connection 7
L
Light Source 271
N
numbers lock key 57, 58
P
Performance Characteristics 271
Physical Characteristics 271
Pitch – Good Read, Beeper 24, 25
Pitch Tolerance 271
Prefix/Suffix 68, 260

Datalogic QuickScan Lite QW2100 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	EAN 5, EAN-13, EAN-8, GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	340 mA
Power source type	DC
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	65 mm
Width	170 mm
Height	70 mm
Weight	119 g
