Product Reference Guide 271
Appendix A
Technical Specifications
Table 1 contains Physical and Performance Characteristics, User Environment and Reg-
ulatory information. Table 2 provides Standard Cable Pinouts.
Table 1. Technical Specifications
Item Description
Physical Characteristics
Dimensions
2.8 in. H x 6.7 in. L x 2.6 in. W
(7.1 cm H x 17.1 cm L x 6.6 cm W)
Weight (without cable) Approximately 4.2 oz. (119 g)
Color Black or White
Electrical Characteristics
Voltage & Current
5.0 VDC +/-10%
Max Operating Current @ 5V < 260mA
Typical Operating (Scanning) Current @ 5V < 180mA
Idle Operating Current @ 5V < 80mA
Sleep/Suspend @ 5V < 2.5mA
Performance Characteristics
Light Source 617nm LEDs
Roll (Tilt) Tolerance ± 45° from normal
Pitch Tolerance ± 65°
Skew (Yaw) Tolerance ± 70°
Scan Angle 56° ± 2°
Typical Depth of Field
5.0 mil 1.5 - 15.0 cm
7.5 mil 0 - 24.0 cm
10 mil (80% UPC) 0 - 38.0 cm
13 mil (100% UPC) 0 - 45.0 cm
20 mil * to 65.0 cm
Minimum Element Width 4 mil
Print Contrast Minimum 15% minimum reflectance

Datalogic QuickScan Lite QW2100 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	EAN 5, EAN-13, EAN-8, GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	340 mA
Power source type	DC
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	65 mm
Width	170 mm
Height	70 mm
Weight	119 g
