Datalogic QuickScan Lite QW2100 User Manual

Interfaces
12 QuickScan
TM
Lite QW2100
Table 1. Available Interfaces
RS-232 FEATURES
RS-232 standard interface
$P,HA05,P

Select RS232-STD
Set RS-232
Interface
Features
starting on
page 37
$P,HA12,P
Select RS232-WN
RS-232 Wincor-Nixdorf
RS-232 for use with OPOS/UPOS/JavaPOS
$P,HA13,P

Select RS-232 OPOS
$P,HA13,P
Select USB-COM-STD
a
USB Com to simulate RS-232 standard interface
USB-OEM FEATURES
USB-OEM
(can be used for OPOS/UPOS/JavaPOS)
$P,HA45,P

Select USB-OEM
Set USB-OEM
Interface
Features
starting on
page 65
a.
Download the correct USB Com driver from www.datalogic.com

Datalogic QuickScan Lite QW2100 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	EAN 5, EAN-13, EAN-8, GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	340 mA
Power source type	DC
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	65 mm
Width	170 mm
Height	70 mm
Weight	119 g
