3.4 Applications
3.4.1 Applications and genset modes
This section about applications is to be used for reference using the particular genset mode as
starting point. It is not suitable for reading from beginning to end.
The unit can be used for the applications listed in the table below.
Application Comment
Engine Control AGC 110/111/112/113
Automatic Mains Failure (no back sync.) AGC 113/145/146
Island operation AGC 111/112/113
Load takeover AGC 113/145/146
Power management AGC 145/146
Genset mode Running mode
Auto Semi Test Man Block
Automatic Mains Failure (no back sync.) X X X X X
Island operation X X X X X
Load takeover X X X X X
For a general description of the available running modes, please refer to the chapter "Running
mode description".
3.4.2 AMF (no back synchronisation)
Auto mode description
The unit automatically starts the genset and switches to generator supply at a mains failure after an adjusta-
ble delay time. It is possible to adjust the unit to change to genset operation in two different ways:
1. The mains breaker will be opened at genset start-up.
2. The mains breaker will remain closed until the genset is running, and the genset voltage and frequency is
OK.
In both cases, the generator breaker will be closed when the generator voltage and frequency is OK, and the
mains breaker is open.
When the mains returns, the unit will switch back to mains supply and cool down and stop the genset. The
switching back to mains supply is done when the adjusted "Mains OK delay" has expired.
For a general description of the available running modes, please refer to the chapter "Running
mode description".
AGC 100 Designer's Reference Handbook
4189340766 UK
Functional descriptions
DEIF A/S Page 14 of 152
