When this input is activated, then the generator breaker cannot close. Inhibit used for GB, where ext. PLC or
other equipment controls when load is on gen-set.
27. MB close inhibit
When this input is activated, then the mains breaker cannot close.
28. Enable mode shift
The input activates the mode shift function, and the AGC will perform the AMF sequence in case of a mains
failure. When the input is configured, the setting in menu 7081 (mode shift ON/OFF) is disregarded.
29. Start enable
The input must be activated to be able to start the engine.
When the genset is started, the input can be removed.
30. Alternative start
This input is used to simulate an AMF failure and this way run a full AMF sequence without a mains failure
actually being present.
31. Switchboard error
The input will stop or block the genset depending on running status.
32. Total test
This input will be logged in the event log to indicate that a planned mains failure has been made.
33. GB spring loaded
The AGC will not send a close signal before this feedback is present.
34. MB spring loaded
The AGC will not send a close signal before this feedback is present.
35. D+ (digital running feedback)
This input is used as a running indication of the engine. When the input is activated, the startrelay is deactiva-
ted. Input for running feedback from charge generator +D terminal. (Runs when charger U > battery voltage).
36. Inhibit EI alarms
When this input is active, it will inhibit all engine interface (option H5) alarms.
The input functions are set up with the PC utility software, please refer to "Help" in this.
6.20 Outputs
The unit has a number of output functions which can be configured to any available relay.
AGC 100 Designer's Reference Handbook
4189340766 UK
Additional functions
DEIF A/S Page 77 of 152
